Insulation materials like PUR and PIR have similar chemical compositions but differ in performance. Both are lightweight and have low thermal conductivity, enhancing building energy efficiency by reducing heating and cooling demands.
PUR foams are produced by reacting a polyol component with an iso component, where OH groups in the polyol balance the NCO groups in the iso, forming urethane linkages. In PIR foams, iso components undergo trimerization to create isocyanurates, while excess iso reacts with polyol to form urethane linkages.
PUR and PIR boards are advanced insulation materials commonly used in construction. PUR (polyurethane) board is a traditional insulation material known for being lightweight, durable, and effective in reducing heat loss. It is primarily used for insulating roofs, walls, attics, and foundations.
PIR (polyisocyanurate) board is a more advanced version of polyurethane, containing more isocyanurate rings, which enhance its resistance to high temperatures and fire. PIR is often preferred in industrial construction or areas requiring greater durability against external conditions.
One of the key differences between the two materials is their chemical composition. PIR panels have better fire resistance due to the additional isocyanurate rings, making them more suitable for areas where the risk of fire is higher. PUR panels, on the other hand, have greater flexibility, which can be an advantage in applications where the material needs to conform to irregular shapes.
PIR boards offer superior resistance to high temperatures, making them a safer and more versatile choice for industrial applications or buildings with a higher fire risk. As a result, PIR panels are often used for insulating flat roofs, external walls, and warehouses.
Both materials provide excellent thermal insulation, but PIR boards have a slightly better thermal conductivity coefficient than PUR boards. This means that for the same thickness, PIR offers better insulation. For projects prioritizing maximum energy savings, PIR panels may be the better option.
A key difference between the two is price. PUR boards are generally more affordable, making them a popular choice for residential buildings where fire safety is less of a concern. While PIR panels are more expensive, their cost is justified by their superior thermal performance and greater resistance to external conditions.
PUR insulation can be injected into wall cavities, creating an energy-efficient barrier. Its foam expands to fill small spaces, forming an airtight seal. According to industry sources, PUR offers “the best thermal performance of all practical full cavity insulants.”
PUR foam can be continuously sprayed onto various surfaces and is generally more cost-effective than other materials, making it ideal for renovations.
In flood-prone areas, PUR’s high water resistance helps minimize water damage in wall cavities, as it does not retain moisture.
While PUR has advantages, PIR (polyisocyanurate) improves upon them. Typically cut into boards, PIR is used in insulated metal panels, wall cavities, and insulated plasterboard. With superior insulation properties, it requires only half the thickness of other mineral-based insulation products.
Like PUR, PIR serves as a low-moisture barrier. However, its key advantage is fire resistance—PIR slows flame spread and reduces smoke emissions compared to PUR.
The differences between PUR and PIR boards determine their applications. PUR boards are ideal for insulating roofs, attics, and walls in residential buildings. Their flexibility makes them suitable for irregularly shaped areas where precise fitting is needed. Additionally, their lower cost makes them a more budget-friendly option for private investors seeking efficient yet affordable insulation.
PIR boards, however, are better suited for demanding conditions, such as insulating industrial or commercial buildings. With higher fire resistance and better insulation performance, they are often used in facilities requiring protection against high temperatures. PIR is also commonly chosen for insulating flat roofs, where the risk of surface heating is greater.
The choice between PIR and PUR panels depends on project requirements and insulation priorities. PIR boards are ideal when fire safety and maximum thermal efficiency are crucial. PUR boards, on the other hand, are a better fit when flexibility, affordability, and versatility are key factors.
For residential buildings with lower fire risk and a need for adaptable materials, PUR boards may be the best solution. In contrast, for industrial or commercial buildings requiring enhanced fire protection, PIR panels are the preferred choice.
Insulation solutions vary, and no single option fits all applications. Each insulation board type has distinct advantages and limitations, making the best choice dependent on specific project needs.
Feature | PIR | EPS | Summary |
Cost | Generally, more expensive | Less expensive | EPS is less expensive, but PIR offers better long-term value through efficiency. |
Performance | Higher R-value per inch, excellent moisture resistance and strength | Good insulation but lower R-value per inch compared to PIR | PIR provides better insulation with less thickness. |
Specifications | Higher fire rating, making it safer in applications where fire risk is a concern | Lower fire rating compared to PIR | PIR has superior fire safety ratings. |
Applications | Suitable for areas requiring maximum insulation in minimal space (e.g., flat roofs) | Versatile, but not as efficient in space-constrained applications | PIR is more suitable for space-constrained applications. |
Energy Cost Savings | Superior thermal efficiency leads to significant savings on energy bills over time | Lower initial cost but less effective in reducing long-term energy bills | PIR offers greater long-term savings on energy bills. |
Feature | PIR | XPS | Summary |
Cost | Can be more expensive but offers better performance per unit cost | More expensive depending on specifications | PIR often provides better value in terms of performance per unit cost. |
Performance | Higher R-value per inch, providing better insulation | Excellent moisture resistance but lower R-value per inch than PIR | PIR provides better insulation efficiency. |
Specifications | Superior fire resistance | Excellent compressive strength, suitable for use below grade | XPS is preferred for its compressive strength, but PIR has better fire resistance. |
Applications | Favoured for its thermal insulation and fire performance | Preferred where water resistance and high compressive strength are critical | XPS is ideal for specific applications, but PIR is more versatile. |
Energy Cost Savings | Leads to greater long-term savings on energy bills | Higher upfront costs with less impact on long-term energy savings | PIR offers greater long-term savings on energy bills. |
Feature | PIR | Phenolic Foam | Summary |
Cost | Generally, more affordable | Usually more expensive due to superior fire performance and manufacturing process | Phenolic Foam is more expensive, but PIR offers a competitive balance of cost and performance. |
Performance | Offers a balance of thermal performance, moisture resistance, and cost | Exceptionally low thermal conductivity (high R-value) and excellent fire resistance | Phenolic Foam has superior thermal and fire performance, but PIR is highly competitive. |
Specifications | Moisture resistance and durability under various conditions | Superior fire resistance and thermal efficiency | Phenolic Foam excels in fire resistance and thermal efficiency, but PIR is more versatile. |
Applications | Versatile for residential and commercial projects | Used in high-specification buildings for fire safety and thermal efficiency | PIR is more versatile, fitting a broader range of applications. |
Energy Cost Savings | Significant potential for energy cost savings, more accessible to a wide homeowner range | Significant potential for energy cost savings, but higher cost may limit accessibility | PIR is more accessible for energy cost savings across more projects. |
Selecting the right insulation is a key decision in any construction or renovation project. PIR insulation offers an excellent balance of thermal efficiency, fire safety, and versatility. While other materials like EPS, HP+, XPS, and phenolic foam have their advantages, PIR often stands out as a top choice for enhancing energy efficiency and reducing long-term costs.
Beyond upfront costs, it's essential to consider long-term savings and performance. The best insulation choice depends on specific project needs, but PIR remains a strong contender for maximizing energy efficiency and building performance.
For high-quality insulation materials, Wiskind offers a wide range of PIR thermal insulation panels. Their products are designed for both residential and commercial construction, providing exceptional durability, high-temperature resistance, and excellent thermal insulation performance.
